ACM Series Air Classifier Mill Grinding Mill For Powder Coating With Good Quality,Meet Customer Requirements
Product Description
The air classifier mill is mainly suitable for fine milling materials into a fineness of 80-300 meshes. It is an air classifying type with no screen. The machine is equipped with a grading mechanism, which can complete the crushing and grading at one time. The negative pressure conveying makes the heat generated in the cavity during the crushing operation continuously discharged, so it is also suitable for the crushing of heat-sensitive materials. The production process is continuous, and the discharged particle size is adjustable.
Typical Application
Food: Biscuit, Cocoa press cake, Dried peas, Potato starch, rice, Soy Protein, Sugar, Cocoa, Wheat gluten, Fennel, Cumin, Corn,Pepper, Soybean meal, Garlic, Pumpkin, Spices, sesame seeds, chili, onion, Ginger, Tea Powder.
Pharmaceuticals: Herbal medicine, Analgesics, Laxatives, Anti-convulsant, Gastric reflux, suppressants, Vitamins, Cultures, Aspirin,Paracetamol.
Chemical: Carbonates, Chlorates, Chlorides, Citric Acid, Fertilizers, Fungicides, Gum Arabic, Gypsum, Hexamine, Insecticides,Metallic Salts, Nitrates, Oxides, Pesticides, Phosphates, Stearates, Talc, Urea Resin.
Features and Benefits
Capable of fine grinding to 300mesh；
Designed for soft to medium-hard materials with a Moh's hardness of 3.5 or less；
Equipped with an internal classification mechanism, grinds and classifies in one step；
Particle size can be adjusted by the speed of the classifier or feed rate；
The high volume of airflow is suitable for thermally sensitive materials；
Compact design & dust-free operation；
Quick-release design for quickly cleaning and maintenance.
Optional Features
Low-Temperature control milling applies to heat-sensitive materials.
Explosion-proof and V/F motor for the requirement.
Product Components
Product Details
●Made of 304 stainless steel●GMP and food grade design●Air classifying●Customized service●High Efficiency Easy Operate●Video technical /Online support.
AIR CLASSIFIER GRINDING CHAMBER & DISC:
●Material of 304 stainless steel ●Alloy steel disc and cutter head
●No screen, simpler classification ●Precision manufactured parts
●Variable frequency speed regulation, easier operation ●Air classifying
●Particle size distribution can be accurately controlled ●Screw feeding
●Frequency control
●Dymatic balance support
DRIVE MOTOR
●Triple phase asynchronous motor
●All copper motor, excellent performance
●Frequency control
●Feeding motor/grinding motor/air classifier motor/air locker motor/draft fan
●Customized
DUST COLLECTOR
●Pulse dust femoval system
●Bag filter
●Visual Window
●Made of 304 stainless steel
Product Parameters
| Model |
Capacity (kg/h) |
Feed Size (mm) |
Fineness (mesh) |
Total Power (KW) |
Speed(r/min) |
| ACM-15 |
10~150 |
≤6 |
80~350 |
16 |
~5500 |
| ACM-20 |
30~200 |
≤10 |
80~350 |
22 |
~4800 |
| ACM-30 |
100~800 |
≤10 |
80~350 |
42.5 |
~3500 |
| ACM-60 |
500~1200 |
≤12 |
80~350 |
84 |
~2800 |
FAQ
Q: What information should be provided to get a quotation?
A: Each air classifying mill pulverizer is specially designed for each customer according to specific material, capacity, feed material size and product size. Before we can work out a detailed proposal or quotation, we have to know the following information:
1) Detailed information of material that you want to mill.
2) Size of your feeding material
3) Particle size after ground
4) Input capacity in kg/h
Q: How the machine will be delivered?
A: The system is usually dismantled into grinding chamber, cyclone, bag house, draft fan and control cabinet for shipping. Each part is packed in box made by plywood.
Q: What kind of after sale service you can provide?
A: We have professional after sale service team who can reach you in short notice. They can supervise the installation, do commissioning and train your workers.
