FL Series Coffee Powder Instant Powder Drinks Making Machine Fluid Bed Granulator
Product Overview
The machine is mainly used for the operations of mixing, granulating,drying and coating of granule,powder material in pharmaceutical industry , foodstuff industry,chemical industry etc. Such as granule of tablet, granule for quick resolving drinking, condiment.
Through powder granulation, improve fluidity, reduce dust flying.
The solubility was improved by powder granulation.
Mixing- granulation -drying is completed in one machine.
Use anti static filter cloth to ensure the safety of the equipment.
Set up the pressure discharge hole, in case of explosion, personnel will not be injured.
There is no dead angle in the equipment, the loading and unloading is light and fast, and the washing is convenient, which conforms to the GMP specification.
High degree of automation, equipped with program control, simulation screen display technology for users to choose.
Parameter
|
Item
|
Model
|
|||||||
|
5
|
30
|
60
|
120
|
300
|
500
|
800-1000
|
||
|
Container
|
Volume (L)
|
22
|
100
|
220
|
420
|
1000
|
1500
|
By client
|
|
Diameter(mm)
|
400
|
700
|
1000
|
1200
|
1600
|
1800
|
||
|
Capability
|
min.(kg)
|
4
|
15
|
30
|
80
|
150
|
250
|
|
|
max.(kg)
|
6
|
45
|
90
|
160
|
450
|
750
|
||
|
Fan
|
Capacity(m³/h)
|
1200
|
1800
|
3000
|
4500
|
7000
|
8000
|
|
|
Pressure(mmH2O)
|
375
|
480
|
950
|
950
|
950
|
950
|
||
|
Power(kw)
|
4
|
7.5
|
11
|
18.5
|
30
|
45
|
||
|
Steam expenditure(kg/h)
|
23
|
70
|
141
|
211
|
366
|
451
|
||
|
Compressed air expenditure(m³/min)
|
0.9
|
0.9
|
1.0
|
1.0
|
1.5
|
1.5
|
||
|
Weight of the main body(kg)
|
700
|
1000
|
1100
|
1300
|
1800
|
2000
|
||
|
Steam pressure(mpa)
|
0.3-6
|
|||||||
|
Temperature(°C)
|
(adjustable at the range from room temperature to 120°C )
|
|||||||
|
Working time(min)
|
45~90
( decided in accordance with the proplerties of raw materials )
|
|||||||
|
Field(%)
|
≥99
|
|||||||
|
Noise(dB(A))
|
≤75dB(A)
(When installation.main machine is separated from fan)
|
|||||||
|
Size(LxWxH)m
|
1.2*0.7*2
|
1.6*
1.1*2.5
|
1.9*
1.4*3
|
2.2*
1.7*3.3
|
2.8*
2*4
|
3*2.3
*4.4
|
||
|
Simplified Diagram
|
|---|
Package & Shipping
